- Designed for installation underneath a bathtub
- No moving parts or electronics
- Maintenance free
- Designed for showers over bath
Easyfit HX 1200
This horizontal waste water heat recovery system is made from ABS and has a copper tubular heat exchanger. This innovative and durable design delivers an efficiency of 47,6% at 5,8 L/Min.
Size & Specifications
Length
1176 mm
Width
386 mm
Weight
9,7 kg
Advice max temperture
60°C
Max capacity potable water
15 l/min
Max capacity waste water
15 l/min
Material & Certification
Max Pressure potable water side
7 bar
Outer shell
ABS
Heat exchanger
Copper
KIWA Certified
Yes
BCGR Certified
Yes
Warranty
5 years
Product number
421009
This horizontal waste water heat recovery system is made from durable ABS outer shell and a copper tubular heat exchanger. This smart and durable design delivers an efficiency of 48,7% at 5,8 L/Min making it the most reliable.
- Suitable for every multifloor building
- No moving parts or electronics
- Easy cleaning and long lasting impact
- For shower over bath
Size & Specifications
Length
1176 mm
Width
386 mm
Weight
9,7 kg
Max Pressure potable water side
7 bar
Material & Certification
Advice max temperture
60°C
Max capacity potable water
15 l/min
Max capacity waste water
15 l/min
Materials outer shell
ABS
Material heat exchanger
Double walled red copper
KIWA Certified
Yes
BCGR Certified
Yes
Warranty
5 years
Product number
421009
How it works
When you shower, valuable energy disappears down the drain. A Recoup waste water heat recovery system captures that heat from the used water and transfers it to the incoming cold domestic water. This reduces the hotwater demand and reduces the load on the water heater, saving both energy and costs.
- Up to 65% heat recovery
- Lower hot water consumption
- Reduce CO₂ emissions while keeping full comfort
Request support
Our technical and sales team is available to answer any questions you may have and provide advice on products and installations
Frequently Asked Questions
What is the difference between a vertical and a horizontal heat exchanger?
The main difference is that a vertical heatexchanger needs to be installed one floor below the bathroom and a horizontal solution can be installed directly on or in the bathroom floor.
Can the Easyfit HX 1200 be installed in any building?
The Easyfit is designed to fit underneath a bathtub. Another option is to install it in the crawlspace underneath the house, where available.
Is the Easyfit HX 2100 truly sustainable?
Absolutely! With the Easyfit HX 2100, you save a lot of energy and therefore reduce CO₂ emissions. An independent environmental study, commissioned by the Dutch government’s energy and sustainability agency, assessed the full environmental impact of the Easyfit HX 2100, including raw materials, production, transport, installation, use, and recycling. The results show that even in single-person households, the Easyfit HX 2100 has a positive environmental effect. In multi-person households, where more showers are taken, the Easyfit HX 2100 provides a significant environmental benefit.
Do I need a specialist to install the Easyfit HX 2100?
It is recommended to have the Easyfit installed by a plumber.
What about health and safety?
The Easyfit complies with all European standards regarding health and safety.
How do I clean the Easyfit HX 2100?
The Easyfit does not require any cleaning.
Is there a risk of clogging?
Just like any other shower tray or drain, there is always a chance of clogging as a result from hair, soap, dirt etc. Using a hair filter on your drain is recommended.
Is there any powersource needed for the Easyfit HX 2100?
The Easyfit is fully passive, has no moving parts and needs no power.
Can I connect the Easyfit HX 2100 to both the water heater and the shower mixer?
Yes, the Easyfit HX 2100 can be connected in three different ways, but most of the time connection method B. is used.
A. To both the water heater and the shower mixer (for maximum efficiency)
B. To the shower mixer only
C. To the water heater only
